Onshore structures

We closely integrate with our clients by understanding their specific challenges and needs. As long-term partners, we are often reappointed by our clients for the safe and timely implementation of fast-track projects.

Our full range of services spans from feasibilities study / concept development to the detailed engineering of the projects. Our highly experienced engineers, all with proven track record of major oil and gas projects, offer flexibility and reliability often exceeding our client’s expectation.

Eien has extensive knowledge and experience with the design, analysis and assessment of structures for the petroleum industry. We design solutions for onshore installations, terminals and pipelines for Oil & Gas and chemical plants.

We provide cost-effective structural design solutions focused on constructability, safety, and ease of installation.

App
Our capabilities in onshore structural engineering include:
  • Design of pipe-rack, stack, equipment supporting structures, reactor/Technological structures supporting process facilities
  • Dynamic analysis of structures, Seismic analysis (SLE/DLE) of structures
  • Finite element analysis / Advanced analysis for the critical onshore structures
  • UG facilities - planning and Design
  • Equipment Foundation design (Static and Dynamic loading condition)
  • Secondary structural design - special pipe supports , equipment access platforms and Cable tray supports
  • Tank farm , tank foundation , process pad detail engineering design
  • Plant Building and civil design of structures
  • Life extension analysis and structural integrity assessment of existing structures , corrosion analysis, remaining strength assessment and retrofitting details
  • Detailed health survey and as building of the existing asset
  • Detail drawings, 3D modelling and fabrication engineering
  • Constructability studies and HAZID studies
  • Cooling tower, water tank, coal belt conveyor structures , PEB, sheds and supporting foundations detail engineering
  • Modularisation of the onshore structures to minimize the site activities
  • Pushover ultimate strength analysis for seismic / wind loads
  • Fatigue life assessment
  • Storage tank design as per API 650
App
Better design, faster delivery, cost effective solutions

We use building information modelling (BIM) to deliver exceptional value to our clients. BIM is a collaborative working philosophy that allows projects to be delivered faster, more efficiently and with significant cost benefits to our clients.

Explosion analysis and hazard management

Explosions can be critical to both the asset and its personnel. Our structural engineering specialists perform advanced explosion analyses to ensure sufficient structural capacity in all critical areas.

Cost estimation based on industry experience

With extensive experience in engineering solutions for the oil and gas industry, Eien provides highly qualified cost estimation. Our cost estimates are applicable throughout the project life cycle from early conceptual and feasibility studies to final design solutions.

Based on information about field output or facility capacity, our specialists develop flow diagrams, concept layouts and master equipment lists and Material Take Offs (MTOs). We have successfully developed the cost estimation for several green field and brown field projects.
